TELEPHONE AND ALARM CABLES
DOMESTIC ALARM CABLES
APPLICATION
Alarm cable with electrostatic shield for alarm systems and signals. Suitable for fixed laying in dry and humid rooms, on-wall and in-wall, outdoor use, no laying underground.
SPECIAL FEATURES
Aluminium tape shielded CEI 20-20 / 20-22 II
EN 50575 : 2014 + A1 : 2016
EN 50575 : 2014 + A1 : 2016
REMARKS
Conform to RoHS directive
Conform to Low-Voltage Directive (LDV) 2014/35/EU
Conform to Low-Voltage Directive (LDV) 2014/35/EU
TECHNICAL FEATURES
Operating temperature
-30°C ÷ +70°C
Rated voltage
0,22 mm2 150V / 0,5 – 0,75 mm2 250V / 1,0 – 1,5 mm2 300/500V
Test voltage
1500 V GR2 / 2000 V GR4
Conductor Class
Bare copper Class 5 DIN VDE 0295 / IEC 60228
Insulation
PVC (Quality TI2)
Core identification
CEI 46-5
Separator tape
Polyester tape
Drain wire
Flexible Bare copper 7×0,15mm
Screening
Aluminium/Polyester tape
Sheath material
PVC (quality TM2) White RAL 9003 GR2 / blue RAL 5015 GR4
Min. bending radius
Fixed installation 4 x cable Ø / mobile use 10 x cable Ø
Other versions
Alarm (LSZH) Low Smoke Zero Halogen
CPR (DoP) – EU 305/11
ITALIAN ALARM CABLES PVC
SYSTEM AVCP 1+
Cca
DOWNLOAD
SYSTEM 3
Dca
DOWNLOAD
SYSTEM 3
Eca
DOWNLOAD
SYSTEM 4
Fca
DOWNLOAD
Additional parameter
s3,d0,a3
ITALIAN ALARM CABLES HF
SYSTEM AVCP 1+
B2ca
DOWNLOAD
SYSTEM AVCP 1+
Cca
DOWNLOAD
SYSTEM 3
Dca
DOWNLOAD
SYSTEM 3
Eca
DOWNLOAD
SYSTEM 4
Fca
DOWNLOAD
Additional parameter
s1a,d0,a1
