TELEPHONE AND ALARM CABLES
VVT F2 TWISTED PAIR
telephone cables, for fixed indoor installations
APPLICATION
Telephone cable for indoor installation, insulated with a special flame retardant PVC compound or low toxic smoke Halogen-free material in accordance with EN-IEC flame and smoke standards.
SPECIAL FEATURES
VVT F2 PVC :
IEC 60332-1-2 : Flame retardant
IEC 60332-3-24 : Circuit integrity
EN 50575 : 2014 + A1 : 2016
IEC 60332-1-2 : Flame retardant
IEC 60332-3-24 : Circuit integrity
EN 50575 : 2014 + A1 : 2016
GGT LSZH :
IEC 60332-1-2 : Flame retardant
IEC 60332-3-24 : Circuit integrity
EN 50267-2-3 : Acidity of gases
EN 61034-2 : Smoke density
EN 50575 : 2014 + A1 : 2016
REMARKS
Conform to RoHS directive
Conform to Low-Voltage Directive (LDV) 2014/35/EU
Conform to Low-Voltage Directive (LDV) 2014/35/EU
TECHNICAL FEATURES
Operating temperature
-5°C ÷ +70°C
Rated voltage
150V
Test voltage
1000V
Conductor class
Bare Cu Class 1 DIN VDE 0812 /IEC 60228
Insulation
PVC (Quality TI2)
Core identification
Coloured pairs
Drain Wire
Clear insulated CuSn solid
Sheath material
PVC (Quality TM2) Grey RAL 7031
Nom. Res. conductor at 20°C
70 Ohm/km
Min. Bending radius
Fixed installation 7,5 x cable Ø
Other versions
GGT (LSZH) Low smoke zero halogen
CPR (DoP) – EU 305/11
VVT F2 PVC
SYSTEM AVCP 1+
Cca
DOWNLOAD
SYSTEM 3
Dca
DOWNLOAD
SYSTEM 3
Eca
DOWNLOAD
SYSTEM 4
Fca
DOWNLOAD
GGT LSZH
SYSTEM AVCP 1+
Cca
DOWNLOAD
SYSTEM 3
Dca
DOWNLOAD
SYSTEM 3
Eca
DOWNLOAD
SYSTEM 4
Fca
DOWNLOAD
